SQUARE D Load Center, 8 Space, 100 A, Circuit Breaker Type QO, Voltage 120/240V AC (CR00465WTA11)


Shipping calculated at checkout

SKU: CR00465WTA11

Only 1 left!

These Square D main lug load centers distribute power downstream from main breakers and are used when all the circuit slots in the main breaker load center are full or when a remote panel is desired. They're used with QO series circuit breakers to protect circuits from overcurrents. They are used in residential, commercial, and industrial applications.

  • Item: Load Center
  • Number of Spaces: 8
  • Amps: 100 A
  • Voltage: 120/240V AC
  • Circuit Breaker Type: QO
  • Included Enclosure Cover: Surface Cover
  • Main Circuit Breaker or Main Lug: Main Lug
  • Max. No. of Tandem Breakers: 8
  • Phase: 1
  • Series: QO
  • Height: 12.56 in
  • Width: 8.91 in
  • Depth: 3 3/4 in
  • For Use With: Square D QO Circuit Breakers
  • Bus Material: Tin Plated Aluminum
  • Short Circuit Current Rating: 10kA
  • Enclosure NEMA Rating: 1
  • Cover Attachment Style: Screw On
  • Cover Closure Method: Lift-Off
  • Recommended Ground Bar Kit: 1D374
  • Recommended Surface Cover: Included
  • Color: Gray
  • Enclosure Material: Steel
  • Enclosure Surface Finish: Enamel
  • Feed Location: Top/Bottom
  • Max. Operating Temp.: 104 Degrees F
  • Min. Operating Temp.: 23 Degrees F
  • Special Features: Green Premium Product, Mercury Free, Toxic Heavy Metal Free
  • Location: Indoor
  • Standards: RoHS Compliant, UL Listed
