(10) FABORY Stainless Steel Slotted Spring Pin, 3/8" X 2-3/4" (183850730992-NBT33)

$9.99

Shipping calculated at checkout

SKU: 183850730992-NBT33

Available Now!
(10) FABORY Stainless Steel Slotted Spring Pin, 3/8" X 2-3/4" (183850730992-NBT33)
(10) FABORY Stainless Steel Slotted Spring Pin, 3/8" X 2-3/4" (183850730992-NBT33)
(10) FABORY Stainless Steel Slotted Spring Pin, 3/8" X 2-3/4" (183850730992-NBT33)
(10) FABORY Stainless Steel Slotted Spring Pin, 3/8" X 2-3/4" (183850730992-NBT33)
(10) FABORY Stainless Steel Slotted Spring Pin, 3/8" X 2-3/4" (183850730992-NBT33)
Description
(10) FABORY Stainless Steel Slotted Spring Pin, 2-3/4"  U51428.037.0275

Technical Specs

  • ItemSpring Pin
  • System of MeasurementInch
  • Spring Pin TypeSlotted
  • Basic MaterialStainless Steel
  • Material Grade420
  • Outside Dia.3/8"
  • Fastener Length2-3/4"
  • StandardsASME B18.8.2
  • Nominal Diameter3/8"
  • Chamfer Diameter0.368"
  • Wall Thickness0.077"
  • Chamfer Length (Min.)0.016"
  • Chamfer Length (Max.)0.095"
  • Actual Dia. (Min.-Max)0.385-0.395"
  • Fits Hole Dia. (Min.-Max.)0.375-0.382"
  • Double Shear Strength (Lbs.)16,300
  • Package Quantity10
