10, General 31162-88-300,1/4" Bore Flanged Bearings, .687" OD, Double Sealed (184012185290-WTA03)

$7.99

Shipping calculated at checkout

SKU: 184012185290-WTA03

Available Now!

10, General 31162-88-300,1/4" Bore Flanged Bearings, .687" OD, Double Sealed(DC)

Item Details
Part#: Part#: 31162-88

Manufacturer: General Brg.
Weight: 0.021 lbs.
Product Name: 30000 Unground Flanged Series Ball Bearing
Description: Single Row Radial Bearing; 1/4" ID x 11/16" OD x 3/8" Wide; Double Sealed; No Snap Ring; Low Precision (Unground)


Specifications
Bore Type Straight Bore - Inch Type Inner Diameter 1/4 in
Outside Diameter 11/16 in Width 3/8 in
Enclosure Double Sealed Snap Ring No Snap Ring
Material Steel Bearing Type Single Row Radial
Precision Level Low Precision (Unground) Radial Internal Clearance C0 - Normal Clearance
Contact Angle 0 Outside Diameter Type Flanged
Preload Level None Ball Material Steel
Cage Material Nylon Capacity Standard Capacity
Locking Device No Locking Device Lubricant General Purpose
Number in Set Single Bearing Outer Ring Width 5/16 in
Seal Material Rubber Seal Type Contact Seals
Dynamic Load Rating 300.00 lbf Flange Outside Diameter 13/16 in
Inner Ring Width 3/8 in Number of Rows 1

Product Information
Features
  • Integral flanges permit through boring of housing, reducing mounting costs
  • Manufactured from selected carbon steel
  • Case hardened
  • Nylon retainers to insure long life and maximum shock resistance
  • Maximum recommended speed is 2,500 rpm
  • Prelubricated with grease
