100 Shakeproof Clevis Pin 5/16" x1-3/8" Steel Zinc Clear Effective Length 1-5/32 (183779872680-NBT06)

$11.99

Shipping calculated at checkout

SKU: 183779872680-NBT06

Available Now!

100

ITW Clevis Pin 5/16 x 1-3/8 Low Carbon Steel Zinc Clear

ITW Shakeproof Clevis Pin 5/16" x 1-3/8" Low Carbon Steel Zinc Clear Effective Length 1-5/32"

CLPZ-0312-1375


Weight (lbs.)
0.0325
MADE IN USA
RoHS Compliant
Yes
Brand:
ITW Shakeproof Group
Manufacturer Part Number:
11-091Z
Material:
Low Carbon Steel
Finish:
Zinc Clear
Type:
Clevis Pin Standard
Inch or Metric:
Inch
Shank Length:
1.375" (1-3/8)
Effective Length:
1.156" (1-5/32)
Head Diameter:
.434"
Head Diameter Maximum:
.444"
Head Diameter Minimum:
.432"
Head Height Maximum:
.100"
Head Height Minimum:
.084"
Hole Diameter:
.141" (9/64)
Hole Diameter Maximum:
.150"
Hole Diameter Minimum:
.135"
Outside Diameter:
.313" (5/16)
Outside Diameter Maximum:
.311"
Outside Diameter Minimum:
.306"
Shank Length Maximum:
1.395"
Shank Length Minimum:
1.375" (1-3/8)
Use with:
BP-213
