Kennametal 25/64" 140° Solid Carbide Jobber Drill, Coolant Through (SQ9651112WT14)


Shipping calculated at checkout

SKU: SQ9651112WT14

Only 1 left!

Solid carbide provides better rigidity than high speed steel. It is extremely heat resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.

Multilayer Titanium Aluminum Nitride (TiAlN) is a blended coating that is more efficient than TIN. It offers a high level of wear resistance at higher cutting speeds and used on high alloy steels and cast iron.

Spiral flutes are constructed with a higher flute angle to remove chips more easily.

Drill Bit Size (Inch): 25/64

Drill Bit Size (Decimal Inch): 0.3906

Drill Point Angle: 140

Drill Bit Material: Solid Carbide

Drill Bit Finish/Coating: Multilayer TiAlN

Flute Type: Spiral

Cutting Direction: Right Hand

Shank Type: Straight

Coolant Through: Coolant Through

Flute Length (mm): 61.00

Overall Length (mm): 103.00

Flute Length x Diameter Ratio: 5xD

Point Type: Standard

Shank Diameter (mm): 10.00

Maximum Drilling Depth (mm): 49.00

Spiral Type: Regular Spiral

Shank Length (mm): 40.00

Specification Designation: DIN

Drill Point Length (mm): 1.70

Web Configuration: Tapered

Number of Flutes: 2

Specification Number: DIN 6537K

Series/List: B052A-CPG
