KENNAMETAL Solid Carbide Jobber Drill 12.3mm 140° B211A12300HP 4099896 (184215096322-BT35)
$149.99
Shipping calculated at checkout
SKU: 184215096322-BT35
KENNAMETAL Solid Carbide Jobber Drill 12.3mm 140° B211A12300HP 4099896
| Manufacturer: | Kennametal | |
|---|---|---|
| Mfr Part #: | 4099896 | |
| Drill Bit Size (mm) : | 12.30 | |
| Drill Bit Size (Decimal Inch) : | 0.4843 | |
| Drill Point Angle: | 135 | |
| Drill Bit Material: | Solid Carbide | |
| Drill Bit Finish/Coating: | Multilayer TiCN | |
| Flute Type: | Spiral | |
| Cutting Direction: | Right Hand | |
| Shank Type: | Straight | |
| Coolant Through: | Coolant Through | |
| Flute Length (mm): | 77.00 | |
| Flute Length (Decimal Inch): | 3.0315 | |
| Overall Length (mm): | 124.00 | |
| Overall Length (Decimal Inch): | 4.8819 | |
| Flute Length x Diameter Ratio: | 5xD | |
| Point Type: | Standard | |
| Shank Diameter (mm): | 14.00 | |
| Shank Diameter (Decimal Inch): | 0.5512 | |
| Maximum Drilling Depth (Decimal Inch): | 2.3622 | |
| Maximum Drilling Depth (mm): | 60.00 | |
| Spiral Type: | Regular Spiral | |
| Shank Length (Decimal Inch): | 1.7717 | |
| Specification Designation: | DIN | |
| Web Configuration: | Tapered | |
| Drill Bit Diameter Tolerance (mm): | 0.007 to 0.025 | |
| Number of Flutes: | 2 | |
| Specification Number: | DIN 6537K | |
| Material Grade: | KCM15 | |
| Series/List: | B211A-HP |
