MILJOCO Pressure Gauge, 0 to 100 psi Range, 3/4 in FNPT, ±3-2-3% Gauge Accuracy (CR00472WTA09)

Air Pressure Test Gauges
• 2" dial Accuracy: 3-2-3% Acrylic lens Black-finished steel housing Brass socket and tube Chrome-plated steel ring 3/4" FPT connection Lower right side connection
Gauges measure air, water, gases, and other light duties suitable for brass components. A coil siphon (sold separately) must be installed on the connection when used for steam service.

• Item: Pressure Gauge
• Gauge Application: Leak Testing
• Gauge Nominal Dial Size: 2 in
• Basic Gauge Case Material: Steel
• Basic Gauge Wetted Parts: Brass
• Gauge Connection Type: FNPT
• Gauge Connection Size: 3/4 in
• Gauge Connection Location: Bottom Right
• Gauge Primary Range Units: psi
• Gauge Primary Range Values: 0 to 100
• Gauge Accuracy: +/-3-2-3%
• Pressure and Vacuum Gauge Type: Pressure Gauge
• Gauge Panel Mountable: No
• Liquid Filled: No
• Gauge Primary Range Smallest Graduation: 2
• Gauge Case Material: Steel
• Gauge Primary Range Numbered Graduations: 20
• Gauge Case Color: Black
• Basic Gauge Socket Material: Brass
• Gauge Socket Material: Brass
• Basic Gauge Sensor Material: Brass
• Gauge Sensor Material: Brass
• Gauge Lens Material: Acrylic
• Basic Gauge Lens Material: Plastic
• Operating Temp. Range: -40 Degrees to 150 Degrees F
• Calibration Certificate Included: No
• Series: P2008LATG
