MILWAUKEE VALVE 1" Threaded Bronze Swing Check Valve (CR00707WTA18)

$79.99

Shipping calculated at checkout

SKU: CR00707WTA18

Only 6 left!

  • Pipe Size: 1"
  • Connection Type: Threaded
  • Body Material: Bronze
  • Cap to Inlet Center: 2 in
  • Flow - Valves: 31.0 gpm
  • Cracking Pressure: 0.75 to 1 psi
  • Application - Valves: General Purpose
  • Flow: 31 gpm
  • Item - Check Valves: Check Valve
  • Full Flow - Valves: Yes
  • Max. Water Pressure - Valves: 200 psi @ 150 Degrees F
  • Max. Temp.: 200 Degrees F
  • Sub-Category: Bronze
  • Max. Pressure: 200 psi Non Shock CWP
  • Max. Water Pressure: 200 psi Non Shock CWP
  • Material of Construction: Bronze
  • Mounting Orientation - Check Valves: Horizontal
  • Standards: NSF/ANSI 372
  • Mounting Position: With Pressure Coming From Under the Disc
  • Length: 3 1/4 in
  • Mechanism and Body Design: Inline Swing
  • Pipe or Tube Size - Check Valves: 1 in
  • Item: Swing Check Valve
  • Seal Material - Check Valves: Bronze
  • Connection Type - Check Valves: FNPT x FNPT
  • Max. Steam Pressure - Valves: Not Rated
  • Cracking Pressure - Check Valves: 0.750 to 1.000 psi
  • Min. Temp. - Valves: -20 Degrees F
  • Max. Temp. - Valves: 200 Degrees F
  • Size: 1"
  • Overall Height: 3 in
  • Width: 1 in
  • Flow Design: Single
  • Seat Material - Check Valves: Brass
  • Body Material - Valves: Bronze
  • Seat Material: Brass
  • Seal Material: Bronze
  • Mounting Orientation: Horizontal
  • Pipe or Tube Size: 1 in
  • Length (Straight Wireway): 3 1/4 in
