MILWAUKEE VALVE Gate Valve, Class 125, Bronze, Solder Connection, Pipe Size - 2" (SQ2449604WT39)

Bronze Gate Valves
Valves act as a positive shutoff and can be used fully open or fully closed. Bronze disc, wedge, stem, and bonnet. Full port. For use in steam, water, and compressed air applications.
Meet MSS SP-80 standards.

• Item: Gate Valve

• Valve Class: Class 125

• Body Material - Valves: Bronze

• Connection Type: Solder

• Pipe Size - Valves: 2"

• Max. Water Pressure - CWP: 200 psi

• Max. Working Steam Pressure - WSP: 125 psi

• Valve Max. Fluid Temp.: 365 Degrees F

• Valve Stem Type: Non-Rising

• Top of Handle to Inlet Center: 7-7/16"

• Inlet to Outlet Length: 4-5/16"

• Stem Material: Bronze

• Bonnet Style: Threaded

• Wedge Material: Bronze

• Handle Material: Malleable Iron

• Handle Type: Hand Wheel

• Standards: MSS SP-80
