NOS, Parker 381-6 Series 50' 3/8" 2 Ply 5000 PSI Medium Pressure Hydraulic Hose (SQ5160333WT25)

Manufacturer: Parker Hose

Type: High Pressure Hydraulic Hose

Compatible Fittings: 43 Series

Applications: Industrial

Cover Color: Black

Cover Material: Synthetic Rubber

For Use With: Parkrimp Equipment; Karrykrimp Equipment

Hose Inner Tube Material: Synthetic Rubber

ISO Ratings: 1436 TYPE 2AT

EN Ratings: 853 TYPE 2SN

Reinforcement: Two Braids Steel Wire

ID (in.): 3/8ID (mm)9.5

Media: Petroleum Base Hydraulic Fluids; Lubricating Oils

Series: 381 Series

Minimum Bend Radius: 5 in.; 125 mm

OD (in.): 0.75OD (mm)19

Rated Pressure: 350 psi; 5.000 MPa

Applicable Standards: MSHA Accepted

Working Temperature Range: -40 to +212 °F; -40 to +100 °C

Working Temperature Range (Oil): -40 to +212 °F; -40 to +100 °C

Working Temperature Range (Air): -40 to +158 °F; -40 to +70 °C

Working Temperature Range (Water): Maximum of +185 °F; Maximum of +85 °C

• Parker's 381 hydraulic hose has a pressure range of 400-88 bar and designed to most common purpose applications.
  381 hose, Universal two-wire construction hose designed to accommodate global customer requirements, is manufactured to strict international quality specifications. Parker’s 381 offers customers consistency of performance combined with continuous availability anywhere in the world.

  It offers a high working pressure, long service life and a wide fluid compatibility.

  The Universal two-wire hose is manufactured to international specifications (ISO 1436-1 Type 2SN)
  The Inner tube is Synthetic rubber.Reinforcement is 2 wire braids steel wire.The Cover is Synthetic rubber.
  Temperature Range is from -40°C to +100°C (-40°F to +212°F).

  Markets:
  •General purpose market.
  •Industrial
  •Transportation
  •Military
  •Construction
  •Agriculture
  •Grounds & Building Maintenance
  •Forestry
  •Utility Equipment
  •Machine Tool
  •Waste & Refuse
  •Material Handling

  Features/Benefits:
  •Universal two-wire hose design manufactured to international specifications
  •Increased working pressures for improved reliability and expanded applications
  •400-88 bar (5800-1300 PSI) working pressure in different sizes
  •Strict international quality specifications
  •Provide consistency of performance

  Applications:
  •Petroleum base hydraulic fluids and lubricating oils
