Remke Dome Cap Cable Gland, black, Polyamide, 3/8" NPT, cable range .19 - .39, QTY: 45 (CR00677WTA18)
$49.99
Shipping calculated at checkout
SKU: CR00677WTA18
| A Dimension (in) | 0.67 |
|---|---|
| B Dimension (in) | 0.59 |
| Body Material | Polyamide |
| Box Quantity | 45 |
| Bushing Holes | 1 |
| Bushing Material | Neoprene |
| C Dimension (in) | 0.87 |
| Cable Range | .19 - .39 |
| Clearance Hole (in) | 0.701 |
| Conduit Size | 3/8 |
| Connector Material | Polyamide |
| Cord Grip Type | Straight |
| Country of Origin | Turkey |
| CSA Specification | 115116 |
| Inside Body Diameter / Body Bore | 0.416 |
| IP Rating | IP68 |
| Max Cable Range over Jacket (in) | 0.39 |
| Maximum Knock Out Size (in) | 0.701 |
| Maximum Operating Temperature (C) | 80 |
| Maximum Operating Temperature (F) | 176 |
| Min Cable Range over Jacket (in) | 0.19 |
| Minimum Operating Temperature (C) | -20 |
| Minimum Operating Temperature (F) | -4 |
| NEMA Rating | 6 |
| Select Color | Black |
| Standard Package Quantity | 50 |
| Tab Info | Cord/Cable Dia., Flammability, Knockout, Ratings/Mtls, Certifications, Approvals, IP Ratings, Thread Specs, Temps |
| Thread Size | 3/8 |
| Thread Type | NPT |
| UL Specification | E199260 |
