Plus -2 More
Shipping calculated at checkout
Item: Thread Forming Tap
Thread Size: #10-32
Thread Standard: UNF
Tap Material: High Speed Steel
Tap Finish: TiCN
Thread Length: 1/2"
Overall Length: 2.38"
75% Thread Drill Size: 4.4mm
Thread Limit: H4
Thread Direction: Right Hand
Primary Material Application: Steel
55% Thread Drill Size: 4.52mm
65% Thread Drill Size: 4.45mm
Coolant Fed: Non-Coolant Through
Extended Neck: No
Features: Blind Holes, Bottoming Entry Taper, Forming Taps
Material Grade - Machining: 5502TC
Measurement System: Decimal Inch
Number of Flutes: 4
Primary Material Application ISO Code: P
Secondary Material Application: Aluminum, Brass, Bronze, Cast Iron, Copper, Stainless Steel
Secondary Material Application ISO Code: K, M, N
Shank Dia.: 0.194"
Shank Length: 1-1/2"
Spiral Direction: Neutral
Tap Chamfer: Bottoming
Tap Grouping: Individual
Tap Style: Thread Forming
Thread Limit / Class of Fit: H4
Threads per Inch: 32 TPI
